15kw Motor Driven Automatic Copper Foil Coil Winding Machine With TIG Welding

1) Description

15kw Motor Driven Automatic Copper Foil Coil Winding Machine With TIG Welding BRJ1000-2 can wind copper or aluminium foil strip with max width 1000mm. This foil winding machine is provided with two pieces of foil decoilers and insulation decoilers, which can provide tension through pneumatic brake system. Moreover, photoelectric sensors are used to make sure the foil edge is neat when winding. Pressing rollers is used to make the foil not reverse when the machine stopps winding. The control system based on PLC can control the machine precisely. Touch screen interface make the operation easy and intuitive.

2) ​Main Components

Main frame, Winding unit, Foil decoiler, Insulation decoiler, End-fill strip feeder, Cleaning system, Cutting system, Foil deburring system, Edge alignment system, Automatic welding unit, Electronic control system and Pneumatic system, etc.

3)Technical Parameters

Typical standard specifications of BRJ1000-2 are shown below, however these can be easily modified as requested.

4) Delivering

Founded in 2011, Zhu Tang (Suzhou) Technology Co., Ltd. is located in Taicang City, Jiangsu Province, China, and is adjacent to Shanghai City. The company specializes in developing, manufacturing and selling transformer making equipment, reactor making equipment, and other similar products, such as foil winding machines, coil winding machines, iron core stacking and tilting platform and silicon iron cut to length line etc. , serves power industry and provides transformer manufacturers, reactor manufactures and other similar manufacturers with products and services. Upholding the concept of continuous innovation, the company creates the value for customers. The company invests 10% revenue for research and develop each year to improve the products and their performance. Now the company holds several patents. With a team of trained engineers and skilled technicians, the company provides different specifications of products to meet customers’ different needs, moreover, the company can design and manufacture the customized products according to customers’ requirements. Based on good quality and reasonable price of the products, the company obtains customer recognition and trust. Besides of many domestic customers, our customers are around the world, including Canada, Russia, Germany, France, South Korea, Vietnam, India, Singapore, and so on.

In 2019, the company established a branch, Hefei Zhutang Technology Co., Ltd, in Hefei City, Anhui Province.
